Citroen Relay 3.5T L3 Diesel 2.2 BlueHDi 140 H2 Window Van Enterprise Lease Deals
Choose from 180 lease deals, starting from £379.95 p/m
Citroen Relay 3.5T L3 Diesel
2.2 BlueHDi 140 H2 Window Van Enterprise
Key info
- Fuel type:
- Diesel
- Transmission:
- Manual
- Body style:
- High Roof Window Van
- CC:
- 2184
- Drive train:
- Front Wheel Drive
- Gears:
- 6
- Vehicle value*:
- £42,239
Performance
- Power:
- 140 bhp
- Torque:
- 350 nm
Metrics
- Length:
- 5,998 mm
- Width:
- 2,050 mm
- Height:
- 2,524 mm
- Wheelbase:
- 4,035 mm
- Fuel tank:
- 90 litres
- Dry weight:
- 2120.0 kg
- Max towing weight:
- 750.0 kg
- Wheels:
- 15" STEEL
- Tyres front:
- 215/70 R15
- Tyres back:
- 215/70 R15
Actual vehicle specification may vary
*Based on the vehicle's P11D value, the value used to calculate Company Car Tax
View full specification
Engine and Drive Train
- Bore:
- 83.8
- Stroke:
- 99
- CC:
- 2184
- Cylinders:
- 4
- Cylinder Layout:
- IN-LINE
- Number of Valves:
- 16
- Cooling System:
- WATER
- Automatic Transmission:
- No
- Manual Transmission:
- Yes
- Valve gear:
- DOHC
- Fuel Type:
- DIESEL
- Catalytic Convertor:
- Yes
- Engine Layout:
- FRONT TRANSVERSE
- Gears:
- 6 SPEED
- Fuel Delivery:
- COMMON RAIL
Performance
- BHP:
- 140
- Engine Power KW:
- 103
- Engine Power RPM:
- 3500
- Engine Torque LBS.FT:
- 258
- Engine Torque NM:
- 350
- Engine Torque RPM:
- 1400
- Engine Torque MKG:
- 35.7
Fuel Consumption - ICE
- EC:
- No
- WLTP - FC (l/100km) - Comb - TEH:
- 11.6
- WLTP - FC (l/100km) - Comb - TEL:
- 6.4
- WLTP - MPG - Comb - TEH:
- 24.4
- WLTP - MPG - Comb - TEL:
- 44.1
Emissions - ICE
- Standard Emissions:
- EURO 6
- WLTP - CO2 (g/km) - Comb - TEH:
- 306
- WLTP - CO2 (g/km) - Comb - TEL:
- 169
Tyres
- Tyre Size Front:
- 215/70 R15
- Tyre Size Rear:
- 215/70 R15
- Wheel Type:
- 15" STEEL
- Alloys?:
- No
- Space Saver?:
- No
- Automatic Clutch:
- No
Vehicle Dimensions
- Length:
- 5998
- Width (excluding mirrors):
- 2050
- Wheelbase:
- 4035
- Width (including mirrors):
- 2690
- Height:
- 2524
- Load Length:
- 3705
- Side Load Door Height:
- 1755
- Lower Rear Door Width:
- 1562
- Rear Door Height:
- 1790
- Load Deck Height:
- 535
- Load Space Width Between Wheel Arches:
- 1422
- Load Width:
- 1870
- Load Height:
- 1932
- Turning Circle - Kerb to Kerb:
- 14.3
- Front Overhang:
- 948
- Rear Overhang:
- 1015
- Side Load Door Width:
- 1250
Weight and Capacities
- Minimum Kerbweight:
- 2120
- Gross Vehicle Weight:
- 3500
- Fuel Tank Capacity (Litres):
- 90
- Max. Towing Weight - Braked:
- 2500
- Max. Towing Weight - Unbraked:
- 750
- Payload:
- 1380
- Load Space Volume:
- 15
- No. of Seats:
- 3
- Plated Front Axle:
- 1850
- Plated 2nd Axle:
- 2000
- Gross Train Weight:
- 6000
General
- Exhaust System:
- CATALYTIC CONVERTER
- Front Brakes:
- VENTILATED DISCS
- Rear Brakes:
- DISCS
- Battery Volts:
- 12
- Front Suspension:
- MACPHERSON STRUTS
- Rear Suspension:
- LEAF SPRINGS
- Alternative Fuel Qualifying:
- No
- Generation Mark:
- 3
- NCAP Overall Rating - LCV:
- 5 Star
- Relative Length:
- L3
- Relative Height:
- H2
- Ghost model for valuation purposes:
- No
- Service Interval Mileage:
- 16000
- Service Interval Frequency - Months:
- 24
- Badge Engine CC:
- 2.2
- Badge Power:
- 140
- Vehicle Homologation Class:
- N1
- Steering:
- PAS RACK AND PINION
- Clutch:
- SINGLE DRY PLATE
- Any aspect of the vehicles safety cause concern?:
- No
- Special Edition:
- No
- Special Order:
- No
- Running Cost League Headings:
- LARGE
Test Cycles
- Emissions Test Cycle:
- WLTP
- RDE Certification Level:
- RDE 2
Actual vehicle specification may vary
Hide full specification
Citroen Relay 3.5T L3 Diesel
2.2 BlueHDi 140 H2 Window Van Enterprise
Brakes
- Anti-lock brake system
- Emergency Brake Assist
- Hill start assist
- Electronic brake force distribution (EBFD)
- Electronic Stability Control (ESC)
- Electric parking brake
Security
- Remote central locking
- Deadlocks
- Rolling code transponder immobiliser
- Thatcham approved category 1 alarm volumetric and perimeter
- Dashboard mounted central locking push button and auto locking above 12 mph
- Automatic door unlocking in event of AEBS activation
- 2x Remote control key
Exterior Features
- Electric front windows
- Black door mirrors
- Side protection rubbing strips
- Black door handles
- High level third brake light
- Black side rubbing strips
- High Beam Assist
- Laminated acoustic windscreen
- Black front and rear bumpers
- Front windows tinted to 30 percentage opacity
- Window glazing to row 2, 3 and nearside sliding side loading door
- Nearside sliding side loading door
- Twin lens door mirrors with electrically adjustable and heated upper mirror
- Aerodynamic kit - Central spoiler, air guides, active grille shutter
- Halogen headlamp with integrated daytime running lights
- Visible VIN at base of windscreen
- Twin glazed and heated rear doors opening to 180 degree
- Glazed sliding side door
Interior Features
- Reach adjustable steering wheel
- Dashboard storage areas
- Dual front passenger bench seat
- 12V socket in cabin
- Hard plastic floor protection in cabin
- Front door pockets with 1.5L bottle holder
- Closed upper and open lower glove boxes
- 8 load tie-down hooks in cargo area
- Two cup holders and mobile phone storage in centre or lower dashboard
- Crepe cloth upholstery with single stitches and headrest
- Front seats with height adjustable head restraints
- 6 way driver's seat with lumbar and armrest
- Mistral black dashboard
- Overhead console with ceiling lamps
- Roof trim in cabin
- Manual air conditioning for cab area with glovebox
- Full steel bulkhead with clothes hook
Driver Convenience
- Tyre pressure monitor
- Lane keeping assist
- Lockable fuel cap
- Multi-function on-board trip computer
- Global telematics box module
- Connected services
- Citroen connect box emergency assist system
- Analogue cluster with central 3.5" digital black and white display
- Rear parking sensors
Safety
- Height adjustable 3-point pre-tensioner seatbelts with force limiter
- Automatic activation of hazard warning lights on major deceleration
- Driver and front passenger airbags
Driver Aids
- Traffic sign recognition
- Electric power steering
- Intelligent Speed Assist
- Cruise control with variable speed limiter
- Driver drowsiness detection
- Advanced emergency braking system - Pedestrian and cyclist
- Driver monitoring camera (Driver attention alert Level - 4)
Technical
- 18L AdBlue tank
Entertainment
- Steering wheel mounted controls
- 5" DAB radio bluetooth and USB
Wheels
- 15" Steel wheel with black centre cap
- Fix and go kit
Wheels
- Spare wheel
- All season mud and snow tyres
Exterior Features
- 270 Degree opening rear doors
- Power folding door mirrors
- Sliding glass in sliding doors
- Fixed towing hook
- 2nd sliding side door (glazed)
Paint
- Metallic - Iron grey
- Metallic - Graphito grey
- Metallic - Cumulus grey
- Solid - Icy white
- Solid - Thunder grey
- Solid - Expedition grey
Safety
- Front side airbag and window bag
Driver Convenience
- Smart tachograph
- Smart tachograph exclusion
- 7" colour touchscreen display with DAB/FM/AM and Apple CarPlay/Android Auto
Interior Features
- Remove bulkhead
- Single passenger seat including armrest and lumbar adjustment, passenger airbag
Technical
- Speed limiter 56mph
- Speed limiter 62mph
- Exclusion speed limiter
Trim
- Crepe cloth - Black with single stitches and headrest
Driver Aids
- Rearview camera with dynamic gridlines
Entertainment
- DAB radio antenna integrated in right external mirror
Packs
- Conversion pack - Relay/e-Relay
- Handsfree pack - Relay
- Techno pack - Relay
Security
- Additional plip key with remote control
Actual vehicle specification may vary. Some standard features may require an additional subscription fee from the manufacturer.
